EEE-FPE561UAP

EEE-FPE561UAP



Производитель:

Panasonic - ECG (VA)
Описание:
 CAP 560UF 25V ELECT FP SMD
Категория:
 Capacitors
Корпус:
 SMD
Год:
 07+08+

Datasheet (Техническое описание) EEE-FPE561UAP

Поиск в бесплатном архиве даташитов datasheet.su


Посмотреть все характеристики
Technical/Catalog InformationEEE-FPE561UAP
VendorPanasonic - ECG (VA)
CategoryCapacitors
Capacitance560??F
ESR (Equivalent Series Resistance)80.0 mOhm
FeaturesGeneral Purpose
Lifetime @ Temp.2000 Hrs @ 105°C
Maximum Temperature-55°C ~ 105°C
Size / Dimension0.394" Dia x 0.402" H (10.00mm x 10.20mm)
Lead Spacing-
Surface Mount Land Size0.406" L x 0.406" W (10.30mm x 10.30mm)
Mounting TypeSurface Mount
Package / CaseRadial - Surface Mount
PackagingDigi-Reel?
Tolerance±20%
Voltage Rating25V
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names EEE FPE561UAP
EEEFPE561UAP
PCE4441DKR ND
PCE4441DKRND
PCE4441DKR
